The High Energy Materials Science Beamline (HEMS) at PETRA III

TL;DR: The HEMS beamline at PETRA III has a main energy of 120 keV, is tunable in the range 30-200 keV and optimized for sub-micrometer focusing with Compound Refractive Lenses.

Abstract: The HEMS beamline at PETRA III has a main energy of 120 keV, is tunable in the range 30-200 keV, and optimized for sub-micrometer focusing with Compound Refractive Lenses. Design, construction, and main funding was the responsibility of the Helmholtz-Zentrum Geesthacht, HZG. Approximately 70 % of the beamtime is dedicated to Materials Research, the rest reserved for “general physics” experiments covered by DESY, Hamburg. The beamline P07 in sector 5 consists of an undulator source optimized for high energies, a white beam optics hutch, an in-house test facility and three independent experimental hutches, plus additional set-up and storage space for long-term experiments. HEMS has partly been operational since summer 2010. First experiments are introduced coming from (a) fundamental research for the investigation of the relation between macroscopic and micro-structural properties of polycrystalline materials, grain-grain-interactions, recrystallisation processes, and the development of new & smart materials or processes; (b) applied research for manufacturing process optimization benefitting from the high flux in combination with ultra-fast detector systems allowing complex and highly dynamic in-situ studies of microstructural transformations, e.g. in-situ friction stir welding; (c) experiments targeting the industrial user community.
