Assessment of Demand Response Impact on the Frequency Stability of Low-Inertia Power Systems
Rui Afonso,João Lopes +1 more
- 25 Jun 2023
TL;DR: Assessment of Demand Response Impact on Low-Inertia Power Systems TLDR: A study analyzed the impact of demand response on frequency stability in the Iberian Peninsula, focusing on scenarios up to 2040. Dynamic models for primary and secondary frequency control were developed for EVs, TCL, and electrolysers. Simulations of reference disturbances were conducted to assess the effectiveness of the implemented demand response measures.
read more
Abstract: This paper describes a study that sought to analyse the impact of an active demand response on the frequency stability of the Iberian Peninsula for operation scenarios extending to 2040. For that purpose, one developed dynamic models for primary and secondary frequency control provision from demand-side resources, namely Electric Vehicles (EV), thermostatically controlled loads (TCL), and electrolysers. Those models were developed under a Matlab/Simulink environment, and added to a two-area control model representative of the Iberian Peninsula interconnected to the CESA area. Then, one ran simulations of reference disturbances (loss of a large generator or distributed generation) in the developed platform, once it was fully implemented.
read more
Chat with Paper
AI Agents for this Paper
Find similar papers on Google Scholar, PubMed and Arxiv
Write a critical review of this paper
Analyze citations of this paper to find unaddressed research gaps
Figures
Figure 5.11: Nadir and RoCoF evolution, for winter peak periods, with and without demand participation in frequency control ![Figure 2.14: Controller for PV de-loaded operation [25]](/figures/figure2-14-1-oh84yr5a769z.png)
Figure 2.14: Controller for PV de-loaded operation [25] ![Figure 2.13: Creation of power reserve in PV systems [25]](/figures/figure2-13-1-4pxovccnmtbn.png)
Figure 2.13: Creation of power reserve in PV systems [25] ![Figure 1.4: Expected inertia evolution in the Iberian Peninsula, considering different scenarios [4]](/figures/figure1-4-1-6gahn7wcdbvz.png)
Figure 1.4: Expected inertia evolution in the Iberian Peninsula, considering different scenarios [4] ![Figure 2.8: Dynamic model of two interconnected control areas [19]](/figures/figure2-8-1-4nz1jlriesey.png)
Figure 2.8: Dynamic model of two interconnected control areas [19] ![Figure 2.25: System response to power imbalances, in different scenarios of frequency control provision [35]](/figures/figure2-25-1-6we6n2145ifr.png)
Figure 2.25: System response to power imbalances, in different scenarios of frequency control provision [35]
![Figure 2.14: Controller for PV de-loaded operation [25]](/figures/figure2-14-1-oh84yr5a769z.webp)
![Figure 2.13: Creation of power reserve in PV systems [25]](/figures/figure2-13-1-4pxovccnmtbn.webp)
![Figure 1.4: Expected inertia evolution in the Iberian Peninsula, considering different scenarios [4]](/figures/figure1-4-1-6gahn7wcdbvz.webp)
![Figure 2.8: Dynamic model of two interconnected control areas [19]](/figures/figure2-8-1-4nz1jlriesey.webp)
![Figure 2.25: System response to power imbalances, in different scenarios of frequency control provision [35]](/figures/figure2-25-1-6we6n2145ifr.webp)
