Open AccessProceedings Article10.1109/ESSCIRC.2011.6044993

A monolithically-integrated optical receiver in standard 45-nm SOI

- 13 Oct 2011

- pp 407-410

TL;DR: This work demonstrates that photonics and electronics can be jointly integrated in a standard 45-nm SOI process and is shown to operate with μA-sensitivity at 3.5 Gb/s.

Abstract: A monolithically-integrated optical receiver for low-energy on-chip and off-chip communication is presented. The monolithic photodiode integration enables the energy-efficient and high-sensitivity sense-amplifier-based receiver design. The receiver is characterized in situ and shown to operate with μA-sensitivity at 3.5 Gb/s with a power consumption of 180 μW (52 fJ/bit) and area of 108 μm2. This work demonstrates that photonics and electronics can be jointly integrated in a standard 45-nm SOI process.

AI Agents for this Paper

Find similar papers on Google Scholar, PubMed and Arxiv
Write a critical review of this paper
Analyze citations of this paper to find unaddressed research gaps

Most frequently asked questions

1. What are the contributions in "A monolithically-integrated optical receiver in standard 45-nm soi" ?

A monolithically-integrated optical receiver for lowenergy on-chip and off-chip communication is presented.. This work demonstrates that photonics and electronics can be jointly integrated in a standard 45-nm SOI process.

Fig. 5. The measurement shows the receiver’s ability to distinguish between a DC optical-1 and optical-0.

Fig. 1. An example optical link with chip-to-chip and intra-chip communication links shown. A CW laser source is coupled onto Chip A through a vertical grating. Two ring-resonant modulators imprint data onto two wavelength-channels, λ0 and λ1, which propagate along the waveguide. The bus is routed over an optical fiber to Chip B. The drop rings on Chip B are each tuned to either λ0 and λ1 to select that channel from the bus and direct it to the correct data receiver. A second set of wavelengths, λ2 and λ3 carry data from Chip B to Chip A.

Fig. 2. Optical data receiver architecture. The LSA (a) is followed by an output buffer stage (d) and dynamic-to-static converter (e), before being fed into the digital backend infrastructre (f). The chip has receivers connected to integrated PDs (g) or electrical diode-emulation circuits (h). The simulation model is shown in (i). A cross-section of the implemented PD and optical mode is shown in (j).
